The stepper motor is a mechanical device that directly converts electrical pulses into angular positions. The angle depends on the number of pulses. Together with other supporting stepper motor drives, it forms a set of simple control and low cost. open l
3-phase stepper motor
The stepper motor is a mechanical device that directly converts electrical pulses into angular positions. The angle depends on the number of pulses. It and its matching stepper motor drive form a set of simple control and low cost. open loop system
57 base
产品型号 | Phase | Microstep (deg) |
Length of motor (mm) |
Motor shaft diamete (mm) |
Rated current (A) |
Holding torque (N.m) |
Rotor inertia (g.cm²) |
Lead-out line | Match driver |
57J1276-658(F) | 3 | 1.2 | 76 | 8 | 5.8 | 1.5 | 480 | 6 | 3DM783 |
86 base
产品型号 | Phase | Microstep (deg) |
Length of motor (mm) |
Motor shaft diamete (mm) |
Rated current (A) |
Holding torque (N.m) |
Rotor inertia (g.cm²) |
Lead-out line | Match driver |
86J1270-650-12(K) | 3 | 1.2 | 70 | 12 | 5.0 | 2.2 | 1100 | 6 | 3DM783 |
86J12103-345-12(K) | 3 | 1.2 | 98 | 12 | 4.5 | 4.5 | 2340 | 3 | 3DM783 |
86J12126-340-HJ | 3 | 1.2 | 126 | 14 | 4.0 | 6.8 | 3500 | 3 | 3DM783 |
110 base
产品型号 | Phase | Microstep (deg) |
Length of motor (mm) |
Motor shaft diamete (mm) |
Rated current (A) |
Holding torque (N.m) |
Rotor inertia (g.cm²) |
Lead-out line | Match driver |
110J12161-360 | 3 | 1.2 | 160 | 19 | 6.0 | 12 | 11900 | 3 | 3DM2080 |
110J12185-360 | 3 | 1.2 | 188 | 19 | 6.0 | 16 | 14900 | 3 | 3DM2080 |
110J12220-360 | 3 | 1.2 | 222 | 19 | 6.0 | 20 | 19600 | 3 | 3DM2080 |
130 base
产品型号 | Phase | Microstep (deg) |
Length of motor (mm) |
Motor shaft diamete (mm) |
Rated current (A) |
Holding torque (N.m) |
Rotor inertia (g.cm²) |
Lead-out line | Match driver |
130J12188-368 | 3 | 1.2 | 191 | 19 | 6.8 | 24 | 26870 | 3 | 3DM2080 |
130J12220-368 | 3 | 1.2 | 236 | 19 | 6.8 | 28 | 33970 | 3 | 3DM2080 |
130J12252-368 | 3 | 1.2 | 256 | 19 | 6.8 | 35 | 41400 | 3 | 3DM2080 |
130J12280-368 | 3 | 1.2 | 273 | 19 | 6.8 | 50 | 47300 | 3 | 3DM2080 |
